Heidenhain 376836-28 ROD 436 Rotation Sensor
ID number：376836-20
Line count：1024
Output signal：HTL
Max. scanning frequency：300.00 kHz
Power supply：10 V … 30 V
Flange version：Synchro flange Ø 58 mm, centering collar 50 mm, bolt circle Ø 42 mm, 3 x M4 Shaft: Solid shaft, diameter 6 mm, length 9.5 mm
Protection rating：IP64 (EN60529)
Operating temperature：-40/+100 °C
Electrical connection：Flange socket M23, male, 12-pin
Connecting direction：radial
