Heidenhain ROD 426 1024 27S12-03 ID 376846-LN Encoder
ID number：376846-LN
Line count：1024
Output signal：TTL
Max. scanning frequency：300.00 kHz
Power supply：5 V (+-10 %)
Flange version：Synchro flange Ø 58 mm, centering collar 50 mm, bolt circle Ø 42 mm, 3 x M4 Shaft: Solid shaft, diameter 6 mm, length 9.5 mm
Protection rating：IP64 (EN60529)
Operating temperature：-40/+100 °C
Electrical connection：Flange socket M23, male, 12-pin
Connecting direction：radial
