Operating Temperature | -34 … 65 °C, -30 … 150 °F |
---|---|
Port Size | 1/4″ ISO G |
Gauge | No gauge |
Gauge Port | 1/8″ ISO Rc |
Maximum Inlet Pressure | 10 bar |
Outlet Pressure Adjustment | 0.3 … 10 bar, 4 … 145 psi |
Relieving / Non Relieving | Relieving |
Flow | 70 scfm |
Materials – Adjusting Knob | Acetal resin |
Materials – Body | Zinc |
Materials – Bonnet | Acetal |
Materials – Elastomers | Nitrile rubber |
Country of Origin | Mexico |
Dimensions – Height | 49 mm |
Dimensions – Length | 106 mm |
Dimensions – Width | 51 mm |
Weight | 0.36 kg |
Number of Cycles | 5000000 |
Range | R72G |
Series | Excelon |
Brand | IMI Norgren |
