TOFI LTF81 851545 Pull Wire Encoder For Absolute Encoder JDCA58-SSI
External dimensions: 80x80mm
Pull cord material: Plastic coated steel wire rope
Pull the rope diameter: Φ 0.8 mm
Pull wire box housing material: Aluminum alloy
Pull at the outlet: ≤4N
Pull the length of each turn of the rope: 200mm
Pull encoder resolution: Length per turn of pull cord/resolution per turn of encoder
Wire pulling speed: 1000mm/s (Max)
Resistance to vibration: 10g, 10… 1500Hz
Operating temperature: – 20 ℃… + 70 ℃
Integrated encoder: Absolute value encoder JDCA58 series
Pull wire box: LTF81-4000
Encoder protection level: IP65(standard)/IP67
Type of connection: Cable length 2 m (optional)
Weight of: ≈750g
